Transducer type
Condenser (back electret)
Operating principle Pressure gradient
Frequency response 30 - 20,000 Hz
Polar pattern Cardioid
Nominal impedance 200Ω
Load impedance > 1000Ω
Max. SPL at 1 kHz136 dB (at 48 V phantom power)
126 dB (at 12 V phantom power)
S/N ratio rel. to 1 Pa 64 dB
A-weighted equivalent SPL. 22 dB
Supply voltage 11 - 52 V phantom power
Phantom power: 48 V
Current consumption < 6 mA
Connection 3-pin XLR, male
DimensionsLength: 100 mm
Diameter: 19.5 mm
Weight without cable 36 g |
 |
