5” woofer; 6.5”
midrange woofer; 1.75” diaphragm compression driver
75° Nominal coverage
angle
Maximum SPL 134 dB
peak
1000 watt Class D
power modules in all models (2 x 500 W continuous)
Onboard mixer with
two combo XLR and ¼” inputs, and stereo RCA inputs
(three audio input sources); two direct channel outputs and
single summed balanced output
Extensive DSP
featuring DEEP™ and Intrinsic Correction™ enhances system
performance
DMT™ (Directivity
Matched Transition) ensures uniform coverage across the entire sound
field
Rugged,
texture-painted birch enclosures
Four-position Mic/Line
gain
Tour-grade 16 gauge
steel grilles
Comfortable
ergonomic handles
35 mm standard
(non-tilt) pole socket
M10 rigging points
for suspended installation
|
